The Flex 18SS is a single-sided bioethanol fireplace insert designed to create a striking flame feature in residential and commercial spaces. With one open viewing side, the flame is presented directly from the front, while the clean-lined, all-flame configuration creates a contemporary interpretation of the traditional fireplace.
|
Designed for true zero-clearance installation, the Flex 18SS can be integrated into feature walls, cabinetry and fireplace settings. Its compact format makes it suitable for dining rooms, indoor and outdoor living areas, and other spaces where a dedicated fire feature is desired.
|
True Zero-Clearance Design The self-contained zero-clearance construction provides flexibility for architects, builders, interior designers and homeowners. The insert can be incorporated into a variety of custom settings without the traditional installation constraints associated with conventional fireplaces. |
|
Indoor & Outdoor Application Powered by e-NRG ethanol fuel, the Flex 18SS is suitable for both indoor and outdoor applications. Its clean-burning fuel system allows the fireplace to be used without conventional gas or wood-fire connections. |
|
Efficient Heating The Flex 18SS uses a 2.5-litre burner that provides approximately 8–11 hours of burn time and delivers 1.7 kW of thermal output. It can heat an average area of approximately 20 m², depending on the environment and installation. |
|
|
|
Simple Installation With no requirement for traditional ventilation or utility connections, the Flex 18SS is designed for straightforward integration into custom fireplace installations. Its compact insert format allows the surrounding design to be completed around the fireplace. |
|
Included Accessories Each Flex 18SS includes Black Glass Charcoal for decorative finishing and an integrated fire screen that sits flush behind the frame. |
| Specification | Details |
|---|---|
| Fuel Capacity | 2.5 L [0.7 Gal] |
| Average Heating Area | 20 m² [215 ft²] |
| Minimum Room Volume | 40 m³ [1,413 ft³] |
| Burn Time | 8–11 hours |
| Thermal Output | 6.1 MJ/h – 5,800 BTU/h – 1.7 kW |
| Weight | 25.70 kg [56.66 lb] |
| Model Dimensions | W 578 mm × D 365 mm × H 807 mm |
| Viewing Area | W 378 mm × D 340 mm × H 502 mm |
| Materials | Mild Steel & Toughened Glass |
| Model Colour | Black |
| Burner Colours | Stainless Steel, Black |
